WinUI apps also deserve E2E!
WinUI apps also deserve E2E.
If you read .NET developers also deserve E2E!, you know e2e-dotnet can drive a browser, and a phone. Last week it learned to talk to a MAUI app through DevFlow. Now the same API can drive a Windows window.
Same locators. Same Agent.ActAsync. A desktop app this time.
What landed
E2E.WinApp is on NuGet, in 0.7.0. It landed in PR #621. The engine drives the app through Windows UI Automation, with the library behind the winapp ui command (Microsoft.Windows.SDK.BuildTools.WinApp.UIAutomation 0.7.1). The package brings that library. dotnet add package is the whole install. No winapp.exe.
WinUI 3, WPF, WinForms, and Win32 all speak UI Automation, so the engine talks to all of them. It runs on Windows only.
The test fixtures are two more packages: E2E.WinApp.NUnit and E2E.WinApp.XUnit.V3. Both are 0.7.0, and both give you a WinAppTest base class. e2e explore and e2e mcp also grew a windows target, so an agent can poke the app from the CLI.
What is Reactor?
The app the engine is tested against is apps/WinAppBenchmark. I wrote it with Microsoft.UI.Reactor 0.1.0-preview.16, so the whole UI is C#. Reactor is an experimental C#-first MVU framework for WinUI. No XAML files, no code-behind. Alexandre Zollinger Chohfi wrote the longer tour on the Windows Dev Blog. It renders real WinUI controls. And it is experimental: no support policy, no API guarantees. He says that up front, and he’s right.
The app starts in one line:
ReactorApp.Run<BenchmarkApp>("e2e Benchmark", width: 480, height: 900);
A control gets its test id in code. This is the email field from the Login Form:
TextBox(email, setEmail, placeholderText: "Email").AutomationName("Email").AutomationId("email-input"),
GetByTestId("email-input") finds that. In XAML the same id is AutomationProperties.AutomationId. The engine reads the UI Automation tree, so either one works.
The benchmark is unpackaged (WindowsPackageType set to None), so the engine can start WinAppBenchmark.exe itself.
Let’s set up the test project
Install the fixture. It pulls E2E.WinApp in with it:
dotnet add package E2E.WinApp.NUnit
xUnit v3 folks want E2E.WinApp.XUnit.V3.
One catch on restore. The UI Automation library ships Windows assets only. A test project on plain net10.0 needs these two lines, or restore fails with NU1202:
<AssetTargetFallback>$(AssetTargetFallback);net10.0-windows7.0</AssetTargetFallback>
<NoWarn>$(NoWarn);NU1701</NoWarn>
Targeting net10.0-windows also works. The sample uses the fallback. The details are in the windows skill doc.
Then e2e.config.json. This is the benchmark’s target, the path the x64 Debug build writes:
{
"targets": [
{
"name": "benchmark",
"platform": "windows",
"app": {
"appPath": "../WinAppBenchmark/bin/x64/Debug/net10.0-windows10.0.22621.0/WinAppBenchmark.exe",
"bundleId": "WinAppBenchmark"
}
}
]
}
appPath is the executable, relative to the folder of e2e.config.json. bundleId is the process name. With both, each test launches that exe fresh, and the agent’s open_app tool knows the app as WinAppBenchmark. A target with bundleId alone attaches to the running app and leaves it running. A windows target takes no app.url.
Your test class:
using E2E.WinApp.NUnit;
public class LoginTests : WinAppTest
{
}
That’s it. WinAppTest builds a WinAppEngine, launches the app before each test, ends it after, hands the agent WinAppTools, and sets the step timeout to 90 seconds. E2E_WINAPP_APP_PATH still wins over the config, so one project can point at a build that lives somewhere else.
Let’s write some tests
The benchmark’s login tests extend WinAppTest (through BenchmarkTest). The [SetUp] loads the account and opens the Login Form scenario. The test itself is locators. No model:
[Test]
public async Task Signs_in_and_logs_out()
{
await Screen.GetByTestId("email-input").FillAsync(_account.Username);
await Screen.GetByTestId("password-input").FillAsync(_account.Password);
await Screen.GetByTestId("login-button").TapAsync();
await Expect.That(Screen.GetByTestId("success-message")).ToHaveTextAsync("Logged in successfully");
await Screen.GetByTestId("logout-button").TapAsync();
await Expect.That(Screen.GetByTestId("login-button")).ToBeVisibleAsync();
}
_account is Credentials.User("benchmark"). The scenario’s account is tester@tester.army / benchmark123, unless E2E_USER_BENCHMARK_USERNAME and E2E_USER_BENCHMARK_PASSWORD say otherwise.
Now the fun one. The scenario suite asks the agent to log in, then checks the same message without another model call:
await OpenScenarioAsync("Login Form");
var account = Credentials.User("benchmark");
await Agent.ActAsync(
"Complete this scenario as the screen instructs: log in with the given username and password",
new ActOptions
{
Params = new Dictionary<string, object?>
{
["username"] = account.Username,
["password"] = account.Password,
},
});
// Trust, but verify 😉
await Expect.That(Screen.GetByTestId("success-message")).ToHaveTextAsync("Logged in successfully");
The model does the clicking. The Expect does not call a model, so a wrong login still fails the test.
OpenScenarioAsync is a helper on the benchmark. It taps the home-list row named "Login Form. ". Your app starts on its own window, so you skip that and go straight to ActAsync.
A few scenarios hide the tree on purpose (Broken Accessibility, Vision Only, the flattened forms). Those have no success-message id to read. They call Agent.AssertAsync with VisionMode.Only and judge a screenshot. The test file says why.
Let’s run it
The benchmark project needs Platform set. Build it for x64, then test. The config already points at that exe:
dotnet build apps/WinAppBenchmark -p:Platform=x64
dotnet test apps/WinAppBenchmark.E2ETests --filter "FullyQualifiedName!~Scenarios"
That filter skips the agent tests. Those need a model login once:
dotnet run --project src/E2E.Cli -- login github-copilot
dotnet test apps/WinAppBenchmark.E2ETests
You need an unlocked, interactive Windows desktop. Pattern actions (invoke, set value, toggle, select) work with the window anywhere. Keys, clicks, drags, and the wheel go through SendInput, and that reaches the window in the foreground only. A locked screen, a disconnected remote desktop, or a CI runner with no desktop session fails those with NOT_ACTIONABLE.
Built the exe somewhere else? E2E_WINAPP_APP_PATH names it over the config.
e2e explore and e2e mcp read the same target. Run them on Windows, from the folder of e2e.config.json:
e2e explore "open the login form and sign in"
e2e mcp
Wait, what’s the catch?
A few. The windows skill doc lists them. These are the ones that will bite you.
Windows only. Starting a session on another OS fails with ENVIRONMENT_UNAVAILABLE. On a non-Windows host a windows target is INVALID_CONFIG before any session opens.
Keys and clicks need the foreground. Window.MinimizeAsync() is there. Keys and clicks need the window restored. Pattern actions still work while it’s sitting in the background.
A packaged MSIX app doesn’t launch from appPath. It starts through a broker and the process exits at once. Put the process name in app.bundleId and start the app yourself, or launch it from the test with Window.OpenAppAsync(name). The benchmark stays unpackaged so the exe path works.
There is no back stack. App.BackAsync is UNSUPPORTED_CAPABILITY. Tap the app’s own Back button. Home_lists_the_scenarios_and_opens_one does that.
A screenshot is the main window only. A flyout, a menu, or a combo box list that WinUI opens in its own popup window is in the observation, and missing from the image. Secure fields in the main window are painted black. A secure field with no box withholds the image.
Two more, before you find them the hard way. video on a windows target is UNSUPPORTED_ARTIFACT. App.ClearStateAsync relaunches the app and deletes nothing. The engine doesn’t know where the app keeps its data, so a test that needs a clean folder removes it before the launch.
Final words
If you have a WinUI, WPF, or WinForms exe, the setup is small. One package, two lines so restore can see the Windows assets, a windows target, some AutomationIds, and a class that extends WinAppTest. Then you get E2E tests on the same API as the browser and the phone, agent steps included.
It wants a real Windows desktop in front of it. If you try it and something breaks, open an issue with what the window was doing. That would help a lot.
The app is apps/WinAppBenchmark. The tests are apps/WinAppBenchmark.E2ETests.
Don’t stop coding!
